3-point internal micrometer set 25-50 mm Borematic 5 pieces

3-point internal micrometer set 25-50 mm Borematic 5 pieces

3-point internal micrometer set 25-50 mm Borematic 5 pieces
Item no: 1001357 345

Online price:

Available in 11-13 working days.

Application
For measuring through-bores and short pilots in series production.

Execution
  • LCD digit size 11 mm
  • Measuring surfaces 6-12 mm made of titanium coated carbide, 12-125 mm made of titanium coated hardened steel
  • Spring mechanism for simple, quick measurements
  • Titanium coated measuring pins offer outstanding durability and impact resistance
  • Display rotates through 330° allowing it to be read at any angle
  • GO/NG tolerance evaluation function

Delivery
Incl. box, adjustment wrench, 1x battery, manufacturer’s test certificate (Borematic only)


Brand: MITUTOYO
Min./max. length measuring range: 25-50 mm
Composition of set: 25-30 mm | 30-40 mm | 40-50 mm | Setting rings dia. 30 mm and 40 mm
Digit increment: 0,001 mm
Number of measurement heads: 3 PCS
Number of setting rings: 2 PCS
IP protection class: 0 - not applicable
Reading Length Metrology: 0,001 mm
Data transmission type: USB
Calibration Group: I | AC
Functions: Absolute function | ABS function | On/Off | Lock-function (Keybord lock) | Preset function | Tolerance value entry

Manufacturer part no.: 568-957-10

EAN no.: 4550501394024

Product Datasheet
