ATORN countersink, 75°, HSS, T=3, 10.0 x 54 mm

ATORN countersink, 75°, HSS, T=3, 10.0 x 54 mm

ATORN countersink, 75°, HSS, T=3, 10.0 x 54 mm
Item no: 1003120 051

Online price:

Available for immediate delivery

Application
For producing 75° counterbores up to 1000 N/mm².

Execution
profile-ground triple-edge countersink with radial relief

Advantage
radial relief ensures optimum chip breaking


Brand: ATORN
Material to be processed: Universal use
Countersink angle: 75 Degree
Cutting material: HSS
Surface: Uncoated
Number of cutting edges: 3 PCS
Tool holding device: HA parallel shank
Spot-facer diameter: 10,0 mm
Tip diameter: 2,5 mm
Shank diameter: 6 mm
Length: 54 mm
f steel 700: 0,12 mm/r
DIN: 0 - not applicable

ATORN-No.: 10640801

EAN no.: 4050293067897

Product Datasheet Datasheet cutting values
