NC SPOTTING DRILL 90° HSSE-TICN HA D 12

NC SPOTTING DRILL 90° HSSE-TICN HA D 12

NC SPOTTING DRILL 90° HSSE-TICN HA D 12
Item no: 1010893 207

Online price:

Available for immediate delivery

Application
For drilling in steel and cast steel, alloyed and unalloyed, up to approx. 1,000 N/mm² strength, grey cast iron, malleable iron, spheroidal graphite iron, sintered iron, nickel silver, graphite, short-chipping aluminium alloys, high-pressure die casting, tough brass. Particularly well suited to precision spotting
and countersinking work on NC and CNC-controlled machines, jig boring machines etc.

Execution
  • Right-cutting
  • Extremely short chip flutes
  • Without chamfers
  • Cone polished section
  • Special drill bit with weak core
  • With straight shank

Notes
Not suitable for drilling deep holes! TiN-coated NC spotting drill and variants with additional tip angle, longer design or with MK shank deliverable on request.

Brand: ATORN
Material to be processed: Universal use
Angle of the tip: 90 Degree
Cutting edge diameter: 12 mm
Length: 102 mm
Shank diameter: 12 mm
Chip flute length: 30 mm
Number of cutting edges: 2 PCS
Cutting direction: Right-hand cutting
f steel 700: 0,11 mm/r
Coolant supply: External

Versions
