Hand tap DIN 352 no. 2 second tap HSS polished M14

Hand tap DIN 352 no. 2 second tap HSS polished M14

Hand tap DIN 352 no. 2 second tap HSS polished M14
Item no: 1014027 122

Online price:

Available in 8-10 working days.

Application
For production of standard ISO DIN 13 metric threads. For unalloyed and low-alloy steels up to 800 N/mm² strength.

Execution
  • Second tap with chamfer shape D with two rings
  • Right-cutting
  • Straight-grooved
  • HSS, ground


Brand: LIZZARD
Thread type x nominal diameter: M14
Pitch: 2 mm
Core hole diameter: 12,00 mm
Length: 80 mm
Shank diameter: 11 mm
Shank square: 9 mm
Colour ring system: Steels
Design: Second tap
Shank style: Cylindrical with square drive
Thread type: Metric thread
Lead angle shape: D
DIN: 352
Cutting material: HSS
Cutting direction: Right-hand cutting
Hole type: Clearance/blind hole ≤ 2.5xD
Surface: Uncoated
Tolerance of screw taps: 6H
Nominal diameter: 14 mm
Twist angle: 0°

EAN no.: 4024496017676
