ATORN die HSSE EN 22568 MF14x1.5 6g outer diameter 38 mm

ATORN die HSSE EN 22568 MF14x1.5 6g outer diameter 38 mm

ATORN die HSSE EN 22568 MF14x1.5 6g outer diameter 38 mm
Item no: 1015219 125

Online price:

Still in stock: 1

Application
For cutting fine metric threads externally in the material groups of steel, stainless steel, non-ferrous metals and special alloys up to a strength of 1300 N/mm².

Execution
right die. tol. 6 g with spiral point, nitrided, pre-slotted and 2.0 pitch

Advantage
  • specialised application with optimised cutting geometry for use in difficult-to-machine materials
  • micro cut edge treatment and special lapping method for excellent process reliability and long service life


Brand: ATORN
Material to be processed: Steel
Thread type: Metric fine thread
Cutting material: HSSE
Tolerance of dies: 6 g
Thread type x nominal diameter: MF14
Pitch: 1,5 mm
Outer diameter: 38 mm
Height: 10 mm
Cutting direction: Right-hand cutting

ATORN-No.: 11190150

EAN no.: 4050293115628

Product Datasheet
