ATORN die HSS EN 22568 BSW 1/2 in 12 speed outer diameter 38 mm

ATORN die HSS EN 22568 BSW 1/2 in 12 speed outer diameter 38 mm

ATORN die HSS EN 22568 BSW 1/2 in 12 speed outer diameter 38 mm
Item no: 1015222 106

Online price:

Available in 8-10 working days.

Application
For cutting BSW (British Whitworth) threads externally in the material groups of steel and non-ferrous metals up to a strength of 700 N/mm².

Execution
right die with spiral point and 1.75 pitch

Advantage
  • universal use for maximum flexibility during application
  • micro cut edge treatment and special lapping method for excellent process reliability and long service life


Brand: ATORN
Material to be processed: Steel
Thread type: Whitworth thread
Cutting material: HSS
Thread type x nominal diameter in inches: BSW 1/2 in
Number of thread starts per inch: 12
Outer diameter: 38 mm
Height: 14 mm
Cutting direction: Right-hand cutting

ATORN-No.: 11190195

EAN no.: 4050293116076

Product Datasheet
