ATORN WK qtr circ mill ctr D=16.0x12x21mm r=3.5 type T4 WK size 40 size=13x4

ATORN WK qtr circ mill ctr D=16.0x12x21mm r=3.5 type T4 WK size 40 size=13x4

ATORN WK qtr circ mill ctr D=16.0x12x21mm r=3.5 type T4 WK size 40 size=13x4
Item no: 1016778 107

Online price:

Available in 4-6 working days.

Application
For producing radii on machining centres and CNC machines.

Execution
  • Solid carbide ultra-fine grain
  • Type N
  • TiAlN-coated


Brand: ATORN
Cutting material: SC
Surface: TiAlN
Type: N
Number of cutting edges: 4 PCS
Radius (R): 3,5 mm
Min. cutting edge diameter (Ø1): 16 mm
Max. cutting edge diameter (Ø2): 9 mm
Length (L1): 21 mm
Replaceable head system: WKS 40
fz steel 1000: 0,08 mm

ATORN-No.: 12040431

EAN no.: 4050293406948

Product Datasheet
