ATORN multi screw-on mill cutter 20 mm shank M10 T=2

ATORN multi screw-on mill cutter 20 mm shank M10 T=2

ATORN multi screw-on mill cutter 20 mm shank M10 T=2
Item no: 1017566 111

Online price:

Still in stock: 3

Application
Dramatically increase your productivity and make great cost-savings – with the high-feed milling cutters. The unique cutting geometries provide extremely smooth running and low cutting forces at maximum feed rates. Our extensive program offers solutions for a wide range of applications in modern machine tools, whether in die and mould making or in general mechanical engineering.

Execution
  • With screw-in thread
  • Wear-resistant, nickel-plated version
  • Robust supports
  • With internal cooling
  • Variable pitch
  • Tightening torque (indexable insert) M3.5 = 3.5 Nm

Advantage
  • Broad range of application
  • Minimum-vibration milling even for long mounting lengths
  • Tooth feed possible up to 3 mm
  • Reduces production times


Brand: ATORN
Max. cutting edge diameter (D): 20 mm
Min. cutting edge diameter (di): 6,9 mm
Clearance length (L3): 30 mm
Thread dimension (d1): M10
Radius, theoretical (Rtheo): 1,5 mm
max. ap: 1 mm
Number of cutting edges: 2 PCS
Suitable indexable insert no. (WSP Typ): 1

ATORN-No.: 10617049

EAN no.: 4050293348576

Product Datasheet
