ATORN indexable insert SNMG 150616-RP4 ACP25T-1

ATORN indexable insert SNMG 150616-RP4 ACP25T-1

ATORN indexable insert SNMG 150616-RP4 ACP25T-1
Item no: 1018581 333

Online price:

Available in 6-8 working days.

Advantage
  • perfect combination of toughness and wear resistance, for high degree of process stability and broad range of applications
  • very robust and stable rake, optimised for high feed rates in the medium to high infeed range in unfavourable cutting conditions


Brand: ATORN
Shape of indexable insert ISO: S
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 15
Thickness of indexable insert ISO: 06
Corner radius of indexable insert ISO: 16
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Medium
Carbide type ISO: P25
Carbide type: ACP25T-1
ISO-Code Rotating: SNMG 150616
Material to be processed: Steel | Cast iron
min./max. ap: 1.00-8.00 mm
f min./max.: 0.10-0.60 mm/U
Materials group: P (primary application) | K (secondary application)
f min.: 0,10 mm/r
max. f: 0,60 mm/r
max. ap: 8,00 mm
min. ap: 1,00 mm
Supply type: Roughing - Stable edge at raised feed values
Chip breaker code: RP4
Min./max. Vc in steel: 115-295 m/min
Min./max. Vc in cast iron: 135-395 m/min

ATORN-No.: 12350887

EAN no.: 4066107045036

Product Datasheet Datasheet cutting values
Versions
loading
Keywords:

You might also be interested in this

  • Ins. holder L 0.780.3232.4D f. groov. ins. DED.04.. and DED.05.. No.18768-18770
  •
    ATORN indexable insert XCNT 070308 SN-TR HC4640
  •
    Ins. holder L 0.780.2020.4D f. groov. ins. DED.04.. and DED.05.. No.18768-18770
  •
    Ins. holder R 0.780.3232.4D f grooving ins. DED.04.. + DED.05.. No.18768-18770
  •
    Ins. holder L 0.780.2525.4D f. groov. ins. DED.04.. and DED.05.. No.18768-18770
  •
    Werkbank 2000x750x840mm 4 Schubladen 2x100/1x200/1x300 75kg Multiplex RAL 5012
  •
    Cabinet with viewing window door MOD.5 7035/7016
  •
    Ins. holder R 0.780.2525.4D f grooving ins. DED.04.. + DED.05.. No.18768-18770
  •
    Werkbank 2000x750x840mm 4 Schubladen 2x100/1x200/1x300 75kg Multiplex RAL 7016
  •
    ATORN twist drill U4 HSSE, DIN 338, 11.11 mm x 142 mm x 94 mm, 118°
    21,60 €
  • Werkbank 2000x750x840mm 4 Schubladen 2x100/1x200/1x300 75kg Multiplex RAL 7035
  •
    Combination workbench series DB W2000xD750xH840mm RAL7035/5010 1xdoor 1xdrawer
