Precision depth calipers bridge length 50x17 mm MR 0-150 mm

Precision depth calipers bridge length 50x17 mm MR 0-150 mm

Precision depth calipers bridge length 50x17 mm MR 0-150 mm
Item no: 1031690 302

Online price:

Available in 7-9 working days.

Application
For measuring bore depths and shoulders.

Execution
  • With friction coupling
  • Scale sleeve and thimble brushed chromium-plated
  • With clamping ring
  • Interchangeable measuring needles in 25 mm increments
  • Measuring bridge and measuring needle ends (dia. 4 mm) hardened and lapped
  • Measuring range 25 mm

Delivery
In case, with adjustment wrench and certificate of constancy of performance


Brand: HHW
Min./max. length measuring range: 0-150 mm
Digit increment: 0,01 mm
Bridge length: 50 mm
Bridge width: 17 mm
Error limit: 0,006 mm
Measuring spindle increments: 0,5 mm
Number of measurement needles: 6 PCS
DIN: 863

EAN no.: 4024496072002

Product Datasheet
