ATORN knife-edge square, flat, hardened 200 x 130 mm DIN 875 precision 00 INOX

ATORN knife-edge square, flat, hardened 200 x 130 mm DIN 875 precision 00 INOX

ATORN knife-edge square, flat, hardened 200 x 130 mm DIN 875 precision 00 INOX
Item no: 1036151 105

Online price:

Will be ordered for you

Application
For testing planar surfaces using the light gap method

Execution
  • Test and side surfaces finely ground
  • Test edges lapped
  • With 2 lapped, graduated knife edges
  • Made of INOX steel
  • Hardened


Brand: ATORN
Limb length x limb length 2: 200 x 130 mm
Angle: 90 Degree
Type: Knife-edge square
Material: Steel, stainless
Cross-section length x cross-section width: 32 x 7 mm
Accuracy class: 00
DIN: 875
Calibration Group: W

ATORN-No.: 30050036

EAN no.: 4050293155112

Product Datasheet
