Tape rule spring steel millimetre scale f. circumf. 2190-3460mm/dia. 700-1100mm

Tape rule spring steel millimetre scale f. circumf. 2190-3460mm/dia. 700-1100mm

Tape rule spring steel millimetre scale f. circumf. 2190-3460mm/dia. 700-1100mm
Item no: 1039580 103

Online price:

Still in stock: 3

Application
For simultaneous measurement of the circumference and diameter of all round elements, e.g. gravure cylinders.

Execution
  • Millimetre scale
  • Cover plate with vernier scale reading 0.1 mm
  • Accuracy according to factory standard
  • Laser-divided graduation
  • Spring steel, with etched graduation

Notes
Larger diameter and rustproof version deliverable on request.

Brand: LIZZARD
Min./max. circumference of measuring range: 2190-3460 mm
Min./max. diameter of measuring range: 700-1100 mm
Scale value: 0,1 mm
Width of band: 15 mm
Display: Analogue
Max. circumference of measuring range: 3460 mm
Max. diameter of measuring range: 1100 mm
Min. circumference of measuring range: 2190 mm
Min. diameter of measuring range: 700 mm
Vernier scale: 0.1 mm

EAN no.: 4024496086030

Product Datasheet
