Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: M
Size of indexable insert ISO: 15
Thickness of indexable insert ISO: 06
Corner radius of indexable insert ISO: 12
Carbide type area ISO: P
Machining conditions for indexable insert: Unfavourable
Carbide type ISO: P35
Carbide type: ACP35T
ISO-Code Rotating: DNMM 150612
Material to be processed: Steel | Stainless steel
min./max. ap: 1.5-8.0 mm
f min./max.: 0.3-8.0 mm/U
Materials group: P (primary application) | M (secondary application)
f min.: 0,3 mm/r
max. f: 8,0 mm/r
max. ap: 8,0 mm
min. ap: 1,5 mm
Supply type: Roughing - Stable edge at raised feed values
Chip breaker code: RP8
Min./max. Vc in steel: 90-190 m/min
Min./max. Vc in stainless steel: 55-180 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370694

EAN no.: 4050293728491
