ATORN die HSS EN 24230 NPT 3/8 in 18 speed outer diameter 45 mm

ATORN die HSS EN 24230 NPT 3/8 in 18 speed outer diameter 45 mm

ATORN die HSS EN 24230 NPT 3/8 in 18 speed outer diameter 45 mm
Item no: 1003150 041

Online price:

Available in 8-10 working days.

Application
For cutting tapered 1: 16 NPT (National Pipe Taper) threads externally in the material groups of steel and non-ferrous metals up to a strength of 700 N/mm².

Execution
right die with spiral point and 1.75 pitch

Advantage
  • universal use for maximum flexibility during application
  • micro cut edge treatment and special lapping method for excellent process reliability and long service life


Brand: ATORN
Material to be processed: Steel
Thread type: National pipe tapered thread
Cutting material: HSS
Thread type x nominal diameter in inches: NPT 3/8 in
Number of thread starts per inch: 18
Outer diameter: 45 mm
Height: 14 mm
Cutting direction: Right-hand cutting

ATORN-No.: 11190186

EAN no.: 4050293115987

Product Datasheet
