Multiplex HPC indexable insert SC/blank girder size 250 dia. 25.0 mm

Multiplex HPC indexable insert SC/blank girder size 250 dia. 25.0 mm

Multiplex HPC indexable insert SC/blank girder size 250 dia. 25.0 mm
Item no: 1010648 134

Online price:

Available in 6-8 working days.

Application
For Multiplex HPC holder art. no. 1010640-1010644.

Delivery
Incl. 1 clamping screw


Brand: HARTNER
Cutting material: SC
Surface: Uncoated
Angle of the tip: 140 Degree
Coolant supply: Internal
Cutting edge diameter: 25 mm
Cutting direction: Right-hand cutting
Number of cutting edges: 2 PCS
Height (h): 15,30 mm
Material to be processed: Non-ferrous metal | Aluminium | Brass | Plastic | Copper
Max. Vc in non-ferrous metals: 150 m/min
Min. Vc in non-ferrous metals: 35 m/min
Min./max. Vc in non-ferrous metals: 35-150 m/min
Point height (l4): 4,60 mm
Size: 250
Suitable for material group N: 1
Thickness of cutting edge: 11,00 mm

Manufacturer part no.: 86724 25,000

EAN no.: 4031096239827

Product Datasheet
