Multiplex index. ins. w/ chamfers w/o chip breaker groove H22+Fire 12.50 mm

Multiplex index. ins. w/ chamfers w/o chip breaker groove H22+Fire 12.50 mm

Multiplex index. ins. w/ chamfers w/o chip breaker groove H22+Fire 12.50 mm
Item no: 1010657 621

Online price:

Available in 6-8 working days.

Application
For hardened steels up to 48 HRC and chilled cast iron.

Execution
  • With polished faces
  • Right-cutting
  • With chamfer without chip divider groove
  • Carbide grade H22/Fire-coated for significant increase in service life and performance


Brand: HARTNER
Cutting material: SC
Angle of the tip: 135 Degree
Coolant supply: Internal
Cutting edge diameter: 12,5 mm
Cutting direction: Right-hand cutting
Number of cutting edges: 2
Material to be processed: Universal use
Max. Vc in cast iron: 120 m/min
Max. Vc in hardened steel 50 HRC: 12 m/min
Max. Vc in stainless steel: 45 m/min
Max. Vc in steel: 115 m/min
Min. Vc in cast iron: 30 m/min
Min. Vc in hardened steel 50 HRC: 10 m/min
Min. Vc in stainless steel: 30 m/min
Min. Vc in steel: 40 m/min
Min./max. Vc in cast iron: 30-120 m/min
Min./max. Vc in hardened steel 50 HRC: 10-12 m/min
Min./max. Vc in stainless steel: 30-45 m/min
Min./max. Vc in steel: 40-115 m/min
Rockwell hardness, HRC: 48 HRC
Suitable for material group H: 2
Suitable for material group K: 1
Suitable for material group M: 2
Suitable for material group N: 3
Suitable for material group P: 1
Suitable for material group S: 3
Thickness of cutting edge: 2,5 mm

Manufacturer part no.: 86702 12,5

EAN no.: 4031096158876

Product Datasheet
