Solid carbide NC spotting drill tip angle 120° solid carbide + TiAlN 3 mm

Solid carbide NC spotting drill tip angle 120° solid carbide + TiAlN 3 mm

Solid carbide NC spotting drill tip angle 120° solid carbide + TiAlN 3 mm
Item no: 1010902 102

Online price:

Available in 6-8 working days.

Application
Drilling and countersinking on NC machines in cast iron, malleable iron, non-ferrous light metals, abrasive plastics.

Execution
  • Tip angle 120°. , right-cutting, spiral-fluted
  • With straight shank in accordance with DIN 6535 HA
  • Right-cutting
  • Spiral-fluted
  • Solid carbide ultra-fine grain/TiAlN-coated


Brand: LIZZARD
Material to be processed: Universal use
Cutting material: SC
Angle of the tip: 120 Degree
Cutting edge diameter: 3 mm
Length: 45 mm
Shank diameter: 3 mm
Chip flute length: 10 mm
Surface: TiAlN
Tool holding device: HA parallel shank
Cutting edge length: 10 mm
f steel 1000: 0,05 mm/r
