ATORN stepped drill bit HSS, with twists, 4.0 mm-12.0 mm, type 1

ATORN stepped drill bit HSS, with twists, 4.0 mm-12.0 mm, type 1

ATORN stepped drill bit HSS, with twists, 4.0 mm-12.0 mm, type 1
Item no: 1010929 101

Online price:

Only while stocks last: 4
Replacement article

Application
For drilling and simultaneous deburring in steel, stainless steel, non-ferrous metals and cast iron.

Execution
Profile-ground and twisted

Advantage
  • Twisted design ensures smooth cutting behaviour
  • No catching on the cutter and low cutting forces and torques
  • High variability: A wide range of bores can be covered with just one tool
  • 3-facet shank ensures good torque transfer in the chuck
  • Reduction of cutting forces


Brand: ATORN
Cutting material: HSS
Surface: Plasma-nitrated
Tool holding device: Parallel shank with three tightening surfaces
Type: 1
Step diameter: 4 mm | 5 mm | 6 mm | 7 mm | 8 mm | 9 mm | 10 mm | 11 mm | 12 mm
Step length: 5 mm
Length: 79 mm
Shank diameter: 6 mm

ATORN-No.: 10643006

EAN no.: 4050293069006

Product Datasheet
