ATORN threading die HSSE M6 1 mm 20 mm 6g 22568

ATORN threading die HSSE M6 1 mm 20 mm 6g 22568

ATORN threading die HSSE M6 1 mm 20 mm 6g 22568
Item no: 1015207 110

Online price:

Still in stock: 1

Application
For tapping metric male threads in the steel, stainless steel, NF metal and special alloy material groups up to a strength of 1300 N/mm².

Execution
Right-handed die, tol. 6g with spiral point (from M2) and nitrided, pre-slotted, 2.0-threaded chamfer

Advantage
  • Specialised insert with optimised chipping geometry for use in materials that are difficult to machine
  • Micro-cutting edge treatment and special lapping process for high process reliability and a long service life


Brand: ATORN
Material to be processed: Universal use
Thread type: Metric thread
Cutting material: HSSE
Tolerance of dies: 6 g
Thread type x nominal diameter: M6
Pitch: 1 mm
Outer diameter: 20 mm
Height: 7 mm
Cutting direction: Right-hand cutting

ATORN-No.: 11190052

EAN no.: 4050293114669

Product Datasheet
