ATORN die HSS EN 22568 UNC no. 5-40 tolerance 2A external diameter 20 mm

ATORN die HSS EN 22568 UNC no. 5-40 tolerance 2A external diameter 20 mm

ATORN die HSS EN 22568 UNC no. 5-40 tolerance 2A external diameter 20 mm
Item no: 1015314 106

Online price:

Available in 8-10 working days.

Application
For cutting UNC (Unified Coarse) threads externally in the material groups of steel and non-ferrous metals up to a strength of 700 N/mm².

Execution
right die. tol. 2A with spiral point and 1.75 pitch

Advantage
  • universal use for maximum flexibility during application
  • micro cut edge treatment and special lapping method for excellent process reliability and long service life


Brand: ATORN
Material to be processed: Steel
Thread type: UNC
Cutting material: HSS
Tolerance of dies: 2A
Number of thread starts per inch: 40
Outer diameter: 20 mm
Height: 5 mm
Cutting direction: Right-hand cutting

ATORN-No.: 11190405

EAN no.: 4050293534184

Product Datasheet
