ATORN cylindrical WK holder D=10.0 x 111 mm, SC X-long, WK size 20 HA shaft

ATORN cylindrical WK holder D=10.0 x 111 mm, SC X-long, WK size 20 HA shaft

ATORN cylindrical WK holder D=10.0 x 111 mm, SC X-long, WK size 20 HA shaft
Item no: 1016760 302

Online price:

Available in 4-6 working days.

Application
The large interchangeable head system is tailored to meet the requirements of users in the high-performance sector and ensures high process stability and profitability.

Execution
  • Solid carbide shank
  • Cylindrical neck
  • Concentricity less than 20 µm
  • HA shank
  • Shank tolerance h6

Advantage
  • Short setup times
  • High stability and rigidity
  • Low-vibration
  • Guaranteed repetitive accuracy

Delivery
Avec clé de montage

Notes
Installation: Clean the interface on the head and holder. Screw the milling head into the holder hand tight. Tighten the milling head to the prescribed torques. CAUTION Risk of injury! - Use gloves when assembling!

Brand: ATORN
Clearance length: 56 mm
Clearance diameter: 9,6 mm
Length: 111 mm
Shank diameter: 10 mm
Replaceable head system: WKS 20

ATORN-No.: 12040447

EAN no.: 4050293407105

Product Datasheet
