SC straight lathe chisel DIN 4971/ISO 1 right setting angle 70° K10 10 Q

SC straight lathe chisel DIN 4971/ISO 1 right setting angle 70° K10 10 Q

SC straight lathe chisel DIN 4971/ISO 1 right setting angle 70° K10 10 Q
Item no: 1018860 223

Online price:

Available in 8-10 working days.

Execution
  • Carbide lathe chisel DIN 4971
  • Right
  • Approach angle 70°
  • With soldered ISO cutting edges in accordance with DIN 4950
  • Cutting edges carbide-tipped.


Brand: LIZZARD
Shank width: 10 mm
Shaft height: 10 mm
Length: 90 mm
Carbide type: K 10/20
Cutting direction: Right-hand cutting
Cutting material: Carbide
DIN: 4971
Shank type: Square
Suitable for material group H: 3
Suitable for material group K: 1
Suitable for material group M: 2
Suitable for material group N: 2
Suitable for material group P: 2

EAN no.: 4030456137261

Product Datasheet
