Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 07
Thickness of indexable insert ISO: 02
Corner radius of indexable insert ISO: 04
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P15
Carbide type: ACP15T
ISO-Code Rotating: DCMT 070204
Material to be processed: Steel | Cast metal
min./max. ap: 0.1-2.5 mm
f min./max.: 0.07-0.25 mm/U
Materials group: P (primary application) | K (secondary application)
f min.: 0,07 mm/r
max. f: 0,25 mm/r
max. ap: 2,5 mm
min. ap: 0,1 mm
Supply type: Smoothing
Chip breaker code: FP1
Min./max. Vc in steel: 100-400 m/min
Min./max. Vc in cast iron: 140-520 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370786

EAN no.: 4050293729412
