ATORN Fatal pull stud similar to DIN 7388, extended by 3 mm

ATORN Fatal pull stud similar to DIN 7388, extended by 3 mm

ATORN Fatal pull stud similar to DIN 7388, extended by 3 mm
Item no: 1021741 111

Online price:

Available in 4-6 working days.

Application
For screwing into tool holders. They differ depending on the machine and spindle type and are used to fix the holders in the machine spindle.

Execution
  • All pull studs made from material 16Mn Cr5
  • Case-hardened HRc 58 ± 2
  • Thread and bore hole soft, black oxide and polished
  • Pull studs with O-ring = sealed

Delivery
1x Fatal pull stud similar to DIN7388

Notes
Further versions available on request (specification of machine types required).

Brand: ATORN
Suitable for tool holding device: SK 40
Design: With O-ring
Outer diameter (D1): 12,95 mm
Bolt diameter (D2): 17 mm
Diameter (D): 18,95 mm
Length (L): 47,5 mm
Coolant supply: Yes
Angle (α/ A): 45 Degree
Length of tenon (L1): 19,25 mm

ATORN-No.: 20803252

EAN no.: 4050293569421

Product Datasheet
