Radial tool holder, shank dia. 50 mm, short 100 mm, right, shape B1, DIN 69880

Versions

Item no: 1021903 313

Online price:

Catalogue price: You save:

Available in 8-10 working days.

Min. order quantity: 1

Application
For external machining. For square steel.

Execution

Shape B1, radial, right-hand
Short design
20MnCr5 hardened to 60 +/- 2 HRC
Full black oxide finish and all functional surfaces ground
With ball spray nozzle and threaded connector for tube fittings

Brand: LIZZARD
VDI mount diameter (VDI Aufnahmedurchmesser d): 50 mm
Form: B1 R
Height (h1): 32 mm
Width (b): 100 mm
Holder width (b2): 50 mm
Width 2 (b1): 16 mm
Height 2 (h3): 35 mm
Height 3 (h4): 60 mm
Holder support length (l1): 30 mm
Length (l): 55 mm
DIN: 69880-1

EAN no.: 4024496065516

Product Datasheet
