Prismatic vice Cekaba jaw width 160 mm, size 4

Prismatic vice Cekaba jaw width 160 mm, size 4

Prismatic vice Cekaba jaw width 160 mm, size 4
Item no: 1027510 104

Online price:

Still in stock: 3

Application
For clamping round, hexagonal and flat material.

Execution
  • With offset, interchangeable prism jaws
  • Open base plate, for clamping and drilling through workpieces
  • Long guide covering the entire clamping range
  • All jaws have horizontal prisms

Advantage
  • Art. no. 1027510 101: With 1 additional vertical prism
  • Art. no. 1027510 102-104: With 2 different sized vertical prisms


Brand: CEKABA
Jaws width: 160 mm
Clamping width: 225 mm
Max. length: 460 mm
Body width: 255 mm
Body height: 102 mm
Chip flute width: 18 mm
Weight: 29 kg
Size: 4

Manufacturer part no.: MOD.BON-4

EAN no.: 4031387100416

Product Datasheet
