ATORN RS-Z 54-75 basic body centric clamping device with spindle

ATORN RS-Z 54-75 basic body centric clamping device with spindle

ATORN RS-Z 54-75 basic body centric clamping device with spindle
Item no: 1027690 401

Online price:

Will be ordered for you

Application
For NC machines and machining centres; increases profitability due to fewer tool changes and shorter run times per workpiece; suitable for use on pallet and robot changing systems.

Execution
  • Robust steel basic body
  • Functional surfaces hardened and polished
  • Centre clamping due to left-hand and right-hand spindle threads
  • High repeat accuracy
  • Easy to use

Advantage
  • Stable clamping for high cutting performance
  • Prepared for ATORN ZPS K20 and Lang Quick Point 52; other adaptations for your machine table available on request

Delivery
1x RS-Z centre clamping device basic body with spindle.

Notes
Jaws not included in scope of delivery. These must be obtained separately as accessories.

Brand: ATORN
Type: RS-Z 54-75
Jaws width: 54 mm
Body width: 54 mm
Body length: 70 mm
Max. length: 74 mm
Overall height: 45 mm
Step height: 22 mm
Step depth: 3 mm
Tension force: 8 kN
Width across flats: 6 mm

ATORN-No.: 22840108

EAN no.: 4066107114985
