Limit plug gauge DIN 2245 bore gauge tolerance range H7 nominal size dia. 12 mm

Limit plug gauge DIN 2245 bore gauge tolerance range H7 nominal size dia. 12 mm

1032100125 Limit plug gauge DIN 2245 bore gauge tolerance range H7 nominal size dia. 12 mm
Item no: 1032100 125

Online price:

Still in stock: 1

Application
For checking maximum and minimum dimensions of boreholes.

Execution
  • Hardened, annealed, ground and lapped
  • Fully cylindrical go and no-go plug gauge
  • Tolerance range: ISO fit H7
  • Gauge steel, hardened, 62 +/-2 HRC

Notes
Other dimensions, tolerance ranges, qualities and designs (e.g. hard chromium plating, carbide, coatings, extended measuring bodies or handles, vent holes, pilot attachments and as flat limit or check gauges) on request.

Brand: ARA
Calibration Group: Z
Nominal diameter: 12 mm
Tolerance class: H7
Material of go side: Gauge steel
Material of discharge side: Gauge steel
Construction type: One-piece
DIN: 2245

Manufacturer part no.: M101LS12H7

Product Datasheet
