Elektr. Drehmoment-Prüfgerät MB 1-25 Nm 1/4 Zoll 6kant-Aufnahme inkl. 2 Adapter

Elektr. Drehmoment-Prüfgerät MB 1-25 Nm 1/4 Zoll 6kant-Aufnahme inkl. 2 Adapter

Elektr. Drehmoment-Prüfgerät MB 1-25 Nm 1/4 Zoll 6kant-Aufnahme inkl. 2 Adapter
Item no: 1055961 100

Online price:

Available in 5-7 working days.

Application
For testing and adjusting torque wrenches, calibrated measuring range in clockwise direction of rotation

Execution
  • Large, high-contrast, easy-to-read backlit LCD display, splash-proof display and membrane keypad
  • 17 mm digits, with traffic light function for measured value evaluation and acoustic signal
  • Robust aluminium housing
  • Desired units can be configured
  • Switchable torque display
    • 1.5-30 Nm: Nm, dNm, cNm, kgf.m, kgf.cm, gf.m, lbf.ft, lbf.in, ft.lb, in.lb, ozf.in, in.oz

    • 10-350 Nm: Nm, dNm, kgf.m, kgf.cm, lbf.ft, lbf.in, ft.lb, in.lb

    • 50-1,100 Nm: Nm, kgf.m, kgf.cm, lbf.ft, lbf.in, ft.lb, in.lb

Advantage
  • Off-grid operation via power bank (5 V/1 A)
  • Simple entry of up to 15 different target values and the relevant permissible tolerance in the range of ± 1 % to ± 15 %
  • Three measuring procedures
    • Automatic breakpoint detection (First Peak - click)

    • Peak value measurement (Final Peak - dial)

    • Tracked measured/display value (track)

Delivery
Robust plastic case with soft foam insert
USB power supply including plug adapters for EU, UK, USA, AUS
2 m USB cable
With factory calibration certificate

Notes
Fastening material not included

Brand: HAZET
Tip type: Internal square | Hexagon socket
Min./max. torque measuring range: 1.5-30 Nm
Drive: 1/4 inch | 3/8 inch
Error limit (%): 1
Max. torque measuring range: 30 Nm
Min. torque measuring range: 1,5 Nm
Type: 7903E
Scale value: 1 nm

Manufacturer part no.: 4000896167425

EAN no.: 4000896167425

Product Datasheet
