ATORN pull stud MAS BT, 45°, SK30, with hole

ATORN pull stud MAS BT, 45°, SK30, with hole

ATORN pull stud MAS BT, 45°, SK30, with hole
Item no: 1021737 401

Online price:

Available for immediate delivery

Application
For tools with steep taper in accordance with ISO 7388-2 (former standard was JIS B 6339 MAS-BT).

Execution
  • Material 16MnCr5
  • Case-hardened HRc 58 ± 2
  • Pull studs without O-ring are SK30

Delivery
1x MAS BT 45° SK pull stud

Notes
Further versions available on request (specification of machine types required).

Brand: ATORN
ISO: 7388-2 B
Suitable for tool holding device: SK 30
Outer diameter (D1): 11 mm
Bolt diameter (D2): 7 mm
Suitable for screw thread (d5): M12
Length (L): 43 mm
Coolant supply: Yes
Angle (α/ A): 45 Degree
Length of tenon (L1): 23 mm

ATORN-No.: 20800050

EAN no.: 4050293200720
